PREMIUM wall-mounted sliding doors

Puertas correderas

PREMIUM wall-mounted sliding doors

In flats with a small area, sliding doors make it possible to create impressive movable walls, which allow for additional free space. Thanks to such a system, it will be easy to separate different zones in the house: the working zone, wardrobe or children's room. This is an excellent option for lovers of large spacious kitchens, which can be separated from the rest of the home if necessary.

price includes: fascia with guide rail (aluminium elements)

FASCIA PANEL LENGTHS FOR THE PREMIUM WALL SYSTEM
„60”	1800 mm
„70”	1800 mm
„80”	1800 mm
„90”	2000 mm
„60”+„60”	1800 + 1800 mm
„70”+„70”	1800 + 1800 mm
„80”+„80”	1800 + 1800 mm
„90”+„90”	2000 + 2000 mm

WIDTH
single-leaf door dimensions on the outer side of the leaf (Ssb, Hsb) and the mounting hole (So, Ho)			double-leaf door - measurements outside of door - leaves (Ssb, Hsb) and mounting hole (So, Ho)
typ	Ssb	So	typ	Ssb	So
„60”	644	620	„60”+„60”	1288	1240
„70”	744	720	„70”+„70”	1488	1440
„80”	844	820	„80”+„80”	1688	1640
„90”	944	920	„90”+„90”	1888	1840
HEIGHT
Height: (Hsb) 2033, (Ho) 2020, height from floor level to top edge of fascia - 2103 mm

Hm - height on the outside of the fascia panel
Ho - height of assembly opening
Hsb - height on the external side of the sash
Hd - height on the external side of the frame
So - width of assembly opening
Ssb - width on the external side of the sash
Sd - width on the external side of the frame

Características técnicas

Modelos disponibles	00
Acabados	PAINTED, HIGH TOP, ECO TOP, PAINTED, LAMISTONE CPL, ECO TOP, SILKSTONE, LAMISTONE CPL, LAMINATED CPL, SILKSTONE, VENEERED, LAMINATED CPL, UNI MAT PLUS, VENEERED, UNI MAT PLUS
Colores	c189, c190, c193, c190, c194, c193, c187, c188, c189, c187, c188
